Phosphate bonded high alumina bricks

Phosphate-bonded high-alumina bricks are made of dense special-grade or first-grade high-alumina bauxite clinker as the main raw material, phosphoric acid solution or aluminum phosphate solution as a binder, and are semi-dry pressed and heat-treated at 400~600℃ to form chemically bonded refractory products. Phosphate-bonded high-alumina brick is unfired brick. In order to avoid large shrinkage of the products during high-temperature use, heating expansion raw materials such as kyanite, sillimanite, pyrophyllite, ซิลิกา, เป็นต้น, are generally required to be introduced into the ingredients. Compared with ceramic-bonded fired high-alumina bricks, they have better spalling resistance, but their load softening temperature is lower, and their corrosion resistance is poor. ดังนั้น, a small amount of fused corundum, mullite, เป็นต้น, need to be added to strengthen the matrix. Phosphate-bonded high-alumina bricks are suitable for cement kilns, electric furnace tops, ladles, เป็นต้น.

Physicochemical indicators of phosphate bonded high alumina brick

รายการ	RSP-75	RSPA-75	RSPT-1
อัล2O3(%) ≥	75	75	80
FeO2(%) ≤	2.1	2.1	1.8
การหักเหของแสง(℃)	1770	1770	1790
ความหนาแน่นเป็นกลุ่ม(กรัม/ซม3) ≥	2.7	2.75	2.9
ความแรงของการบดเย็น(MPa) ≥	70	75	80
0.2MPaSoftening Temperature Load Degree T0.6 (℃) ≥	1350	1300	1520
Thermal Shock Resistance(1100℃) Water Quenching (Cycle) ≥	20	20	15

Characteristics of phosphate bonded high alumina bricks

Alumina bauxite uses high-quality raw materials combined with aluminum dihydrogen phosphate and is finally dried in a drying furnace. It has high refractoriness, good wear resistance, มีความแข็งแรงสูง, และทนต่อแรงกระแทกจากความร้อนได้ดี, so it is very suitable for cement kiln transition zone and cooling zone lining materials. With high load refractoriness temperature, ขนาดที่แม่นยำ, and stable performance, this brick has a short construction period and is energy-saving.

Application of phosphate bonded high alumina refractory bricks

• Inorganic non-metallic materials industry: cement kiln, เตาเผาแก้ว, ceramic kiln, เป็นต้น.
• อุตสาหกรรมโลหะวิทยา: steelmaking furnace, steel rolling heating furnace, soaking furnace, เป็นต้น.
• อุตสาหกรรมเคมีภัณฑ์: coal gasification furnace, coke oven, calcium carbide furnace, เป็นต้น.
• Other industries include garbage incinerators, หม้อไอน้ำ, เป็นต้น.
